<h2>Why Change a Valve?
Debris jamming the diaphragm, solenoid burnout, or freeze cracks. Rule out simpler issues first with the repair guide.
Tools & Parts</h2>
The points below organize this decision into checks that can be observed before the next adjustment.
- New valve (Rain Bird DV, Hunter PGV, or Orbit)
- PVC primer & cement
- PVC hacksaw
- Screwdrivers, wrench, bucket
- Wire strippers & waterproof nuts
<h2>Remove Old Valve
Shut off water, run a zone to relieve pressure. Remove solenoid, bonnet, diaphragm, spring. 5in. See installation guide for pipe sizing tips.
Install New Valve
Dry-fit with repair couplings. Prime, cement, push, hold 15s. Hand-tighten following flow arrows.
Wire Solenoid
Strip 1/2in, twist, cap with waterproof nuts. Wrap with tape. See the sprinkler system guide for controller wiring.
Cost
DIY $15-50. Pro $150-300/valve. See full cost breakdown.
Common Mistakes</h2>
These failure modes are easiest to catch before changing parts or extending the zone.
- Not depressurizing line
- Mixing cement brands
- Overtightening bonnet
- Skipping wire test (20-60 ohms)
