Irrigation Pumps: Selection, Installation & Troubleshooting Guide
My sprinklers turned into a sad trickle in June. The grass on my back slope turned brown. I checked the city water pressure. It was fine at the house. But I had a long uphill run to my back yard. The pressure dropped to 18 PSI at the last head. That is not enough. I needed a pump. I spent three weeks researching pump types. I wish I had done it before my grass died.
What type of pump do you need for your irrigation system?
You need either a centrifugal pump or a submersible pump. Centrifugal pumps sit above ground and pull water from a source. Submersible pumps sit in the water and push it up. Centrifugal pumps cost $150 to $400. Submersible pumps cost $300 to $800. I use a centrifugal pump for my lake-fed system. It handles 30 GPM at 50 PSI. Submersible pumps work better for deep wells over 25 feet. My neighbor uses a submersible in his 100-foot well. Both types need priming before they work.
A jet pump is another option for shallow wells under 25 feet. Jet pumps cost $200 to $500. They work by creating suction. They are less efficient than centrifugal pumps. I avoid jet pumps for large irrigation systems. The efficiency loss adds up over a full season. A 1 HP centrifugal pump delivers about 20 GPM at 40 PSI. A 1 HP jet pump delivers 10 GPM at the same pressure. The difference is significant. Choose your pump type based on your water source depth. Surface water needs a centrifugal pump. Deep wells need a submersible. Check your system design before buying a pump. The pump must match your zone flow and pressure needs.
How do you calculate the right pump size and horsepower?
Calculate total flow first. Add the GPM of every sprinkler head on your largest zone. Then add pressure requirements. Include elevation gain, pipe friction loss, and head operating pressure. I use this formula: Total Head = Elevation Head + Friction Loss + Operating Pressure. Elevation head is 0.433 PSI per foot of rise. If the highest head is 20 feet above the pump, that is 8.66 PSI. Friction loss for a typical zone is 5 to 10 PSI. Operating pressure is 40 PSI for rotors. Total needed is 54 to 59 PSI.
Convert that to horsepower. A 1 HP pump at 40 PSI delivers about 20 GPM. A 1.5 HP pump delivers 30 GPM at 50 PSI. A 2 HP pump delivers 40 GPM at 55 PSI. Pump prices range from $150 for 0.5 HP to $600 for 2 HP. I oversized my pump by 20%. The pump runs at 80% capacity instead of 100%. This extends pump life by years. My 1.5 HP pump cost $350. It handles my 6-zone system easily. Each zone runs at 12 GPM and 50 PSI. The pump cycles on and off with a pressure switch. It only runs when a zone is active. This saves electricity and wear.
How do you install a lawn irrigation pump?
Install the pump as close to the water source as possible. Every foot of suction pipe reduces efficiency. Keep suction lift under 15 feet for centrifugal pumps. Use a foot valve with a strainer at the water source. This keeps the pump primed and stops debris. I installed my pump in a small shed near my lake. The suction pipe is 10 feet of 1.5-inch schedule 40 PVC. The discharge pipe is 1.25-inch PVC to the main line. The pump sits on a concrete pad. It costs $50 for the pad materials.
Wire the pump to a dedicated 240-volt circuit. Most pumps over 1 HP need 240 volts. A 1.5 HP pump draws about 10 amps at 240 volts. Use 12-gauge wire for a 20-amp circuit. Install a disconnect switch within sight of the pump. This is required by code. I hired an electrician for this part. It cost $200 for the circuit and disconnect. The pump cost $350. The fittings and pipe cost $80. Total installation was $630. Follow the pump manual for priming instructions. Fill the pump housing with water before starting. Running it dry destroys the impeller in seconds. A dry-run pump costs $150 to replace the seal.
Why is your irrigation pump losing pressure and how to fix it?
Three things cause pressure loss. A clogged intake strainer, a leaking suction line, or a worn impeller. I check the intake strainer first. Debris blocks the water flow. A clean strainer fixes 60% of pressure problems. I clean mine every two weeks during peak season. It takes five minutes. Unscrew the strainer housing. Rinse the mesh with a hose. Reinstall and test. If pressure returns, you found the problem.
Suction line leaks are harder to find. Air gets pulled into the pump through a tiny crack. The pump loses prime and pressure drops. I test for suction leaks by pouring water over suspect joints. If the pump primes while water covers the joint, I found the leak. I replace the damaged section of pipe. A 2-foot section of 1.5-inch PVC costs $2. A coupling costs $1. The fix takes 30 minutes. Worn impellers happen after years of use. The impeller blades erode from sand and grit. A new impeller costs $30 to $80. I replaced mine after 5 years. The pressure went from 35 PSI back to 52 PSI. Regular maintenance extends pump life significantly. Change the oil annually on pumps with oil reservoirs. A well-maintained pump lasts 10 to 15 years. A neglected pump fails in 3 to 5 years.
Check your pressure switch settings too. The switch turns the pump on at a low pressure and off at high pressure. Typical settings are 30 PSI on and 50 PSI off. If the switch is set wrong, the pump cycles too often. That wears out the motor and contacts. A new pressure switch costs $15. I adjust mine with a simple Allen wrench. The adjustment takes 2 minutes. Pair your pump maintenance with a good controller schedule for maximum efficiency. The pump and controller work together to save water.
References
Here’s my take:
Maintenance review – last checked August 3, 2026
- Originally published or scheduled: 2026-08-05
- Last reviewed: August 3, 2026
- Decision focus: available flow, static and dynamic pressure, pipe losses, pump limits, filtration, and safe testing
- Status: Updated for current editorial use; local codes, water restrictions, equipment manuals, and site conditions still control the final decision.
This page is a practical irrigation reference, not a substitute for local plumbing, electrical, water-quality, backflow, or landscape regulations. A correct answer depends on the water source, pressure and flow, pipe size, soil, plant demand, slope, climate, and the actual equipment installed. Treat old product names, prices, pressure figures, and seasonal dates as starting points that need verification.
What should be checked before changing the system?
Record the symptom or goal, the affected zone, the date, the weather, the controller program, the water source, the pressure reading, and any recent repair. Check whether a valve is open, whether a filter or nozzle is blocked, whether a backflow device is installed correctly, and whether the system is mixing incompatible heads or emitters. For electrical work, shut off power and follow the controller and pump instructions. For compressed air, chemical injection, trenching, or backflow work, use the equipment manual and qualified local help when the task exceeds ordinary homeowner maintenance.
A repeatable field method
- Inspect the zone while it runs and mark every dry spot, leak, misting nozzle, flooded area, and low-pressure symptom.
- Test one variable at a time: valve operation, filter condition, pressure, flow, nozzle pattern, emitter output, sensor signal, or schedule.
- Compare measured output with the design intent instead of adjusting by appearance alone.
- Make the smallest change that addresses the measured cause.
- Run the zone again, check adjacent zones, and record the result.
- Update the valve, zone, part, setting, and date in a repair log.
Common failure modes
Avoid increasing run time to hide a clogged filter, replacing a nozzle without checking pressure, mixing spray and rotor precipitation rates in one zone, putting drip tubing after an unsuitable regulator, using graywater without checking local rules, or blowing compressed air through equipment that is not rated for it. Also avoid assuming that a smart controller’s recommendation is correct without checking the weather source, soil, plant type, and actual catch-can or flow observations. More water is not a universal fix; it can create runoff, disease pressure, nutrient movement, erosion, or root problems.
Verification and maintenance record
After the repair or installation, record the component, model, setting, pressure, flow, run time, date, and observed result. Recheck the zone after the next significant weather event and at the next seasonal startup or shutdown. Keep a photo of valve boxes, wiring, filters, and unusual fittings. A dated record makes future troubleshooting faster and helps a professional understand what has already been tested.
Sources and boundaries
Use current guidance from the U.S. EPA WaterSense program, USDA Natural Resources Conservation Service, local water utilities, manufacturers, and the authority having jurisdiction. Local rules control backflow, graywater, fertilizer injection, wells, discharge, trenching, and licensed work.
- EPA WaterSense irrigation
- EPA WaterSense labeled controllers
- USDA NRCS irrigation water management
- Irrigation Association backflow prevention resource
